Germany European standard Plug Extension Cable reel empty plastic coaxial cable reel drum coaxial cable reel

Basic technical parameter

 Extension Cable reel QC3350A

Drum Material

PP Plate

Drum Diameter

235mm

Galvanized Plate Thickness

0.6mm

Sockets Material

New PP

Plug Type

Germany/European/Schuko Plug

Rain Cover

IP20

Triangular Bracket/Stand

Spray Printed Iron Tube

Iron Tube Diameter

19mm

Max load Capacity

50Mtr.

Cable

PVC Warped

Cable Range

From H05VV-F 2X0.3MM2 To H05VV-F 3G2.5MM2

Current/Voltage

Depend on what kind of cable u use.

How to make a good cable reel ?

1.Clearly know customer’s demand

Communicate with customer about their demands

2.Examine sample

1.use ruler measure drum’s diameter

2.use ruler measure bracket tube’s diameter

3.use micrometer measure cable and each pc of copper’s diameter

3.Buy the material of which need to make cable reel

Like iron tube; Iron plate; cable, etc.

4.Arrange the production

1.use punch machine make the Iron plate, make sure the diameter is same with customer’s needs.

2.use cutting machine cut bracket tube, make sure the length is just fine and no waste ,then use tube bender to warp the tube,

3.use injection machine to product the sockets drums & plugs.

4.use punch machine to product Internal wire; Live contacts (L and N)/L; Earth contact; &Copper accessory/

5.infrom the print house prepare the inner box and out box or customer’s label

5.Assembling

Connect each part together

6.Examine the end products

Put each piece of cable reel under the testing machine, see whether it’s galvanized or high pressure resistant

7.Package

Paste customer’s label on the drum; then put each goods into the box, finally packing with 4 cross packing belt to fasten the box.

8.Delivery

Delivery on time
